50ton/hour rock gold mine separating plant

1.Gold mining machine technical process
The Raw material into feed hopper then into shaking feeder then well distributed into the jaw crusher 500-750# to be crushing then mineral getting into reversible conveyor to be secondary crushing from reversible conveyor,the crushed mineral getting into ball mill to be grinding then into spiral classifier the mineral size≤6mm into 2set 1200# horizontal automatic discharge centrifugal concentrator to get gold concentrate,the tailings into 6s shaking table to be secondary gold separating.
The gold concentrator from horizontal gold concentrator into gold amalgamator to get pure gold.

2.Gold mining machine detail parameter

• 2745ball mill specifications
  Motor:JR-8-570kw-10000v/380v                                             Brand:Handan sida/sanyang kaitai,china
  Reducer:ZD80(forging steel shell)                                           Brand:Zibo xinxing
  Gearwheel the small one:Material forging steel  45#               High-frequency quenching
  Gearwheel the big one:Material forging steel  45#                   Width320mm
  The cover of barrel body:Material forging steel 35#                 Thickness≥60mm
  Main bearing:30031-1000                                                         Brand:Wafangdian bearing manufacturing co.,ltd
  Thickness of barrel body ：25mm
  High manganese steel liner:1pcs,Material of Mn13                  Thickness50mm-70mm
  Overall pinion plate: high - strength and stable 1pcs
  Overall steel bottom frame: (the type no need installation for debugging ) 1pcs;400#U steel
  Starting control cabinet: 1set
  Drum feeder: 1 set double spiral reinforced
  Steel ball needed：35ton

• 2400x13000 spiral classifier
  The thickness of the channel(tank) is 8mm*2;
  Main spindle 425x25mm,seamless steel tube*2;
  Spindle bracket 12mm;Large blade 8mm;
  Small blade polyurethane main reducer ZL65*2;
  Main motor Y-6-22kw*2;
  Length of channel(tank): 11500mm;Spindle bearing drive,Lift motor 4kw*2, lift reducer WXJ180*2 Lift motor4KW*2
