100-150m3/hour gold mining trommel machine

mobile gold mining machine

Technical process-Gold mining machine,mining machinery
The Raw material into vibrating feeder,then screening the one in big size stone to reduce the abrasion of trommel screen,the other into trommel screen to be classified into 4size 0-6mm; 6-10mm; 10-30mm ＞30mm
＞30mm waste material transported by conveyor into scrap area；
10-30mm material transported by conveyor into destination area；
6-10mm material transported by conveyor into destination area；
0-6mm material into mineral box and send to 1200# horizontal automatic discharge gold concentrator by 1set 4 inch sand pump to get concentrate，the waste material discharged from discharge pipe.

Detail parameter-Gold mining machine,mining machinery

Production Name	Specification	Quantity	Power	Unit price	Total price	Remark
Base plate	Length 17.5m	1pcs	-			Used type
Vibrating feeder	2000*2200	1pcs	5.87			Including vibrating feeder
Transport conveyor	Belt width 800mm,pole length 7m	1pcs	7.5
Trommel screen	Inner diameter 1.3m,outer diameter 1.6m,screen mesh 4.3m	1set	11
Centrifugal concentrator	1200# horizontal gold concentrator	1set	21.5
Transport conveyor	Belt width 600mm,pole length 6m	3pcs	5.5*3
Sand pump&mineral box	4inch sand pump+11KW motor+mineral box	1set	11
Centrifugal pump		1pcs	5.5
Driving&directions system	2axles 8wheels	1set	-			Customized
Electric box		1set	-
Total power	78.87KW
