River gold mining machine bucket chain dredger

River gold mining machine bucket chain dredger introduction
Bucket chain dredgers are designed to fit different soil textures except rock. With big dredging depth and little dredging error, this series of dredgers are best suited for projects like ports. One dredger in this series,the most cost-effective producing unit can complete the integrated procedure of digging, washing and separating sand from gravels.

River gold mining machine bucket chain dredger detail parameter

Dredger Model	Bucket Amount	Pontoon (L*W)(m)	Dredging Depth(m)	Length of big arm(m)	Working Capacity(m3/h)	Engine of Diesel
GCLD-40	40-60	11*1.5	1.5-5	12/8	80-200	1095-1100
GCLD-60	60-80	12*1.5	1.5-5	13/10	80-200	1095-1105
GCLD-80	80-95	16*1.5	1.5-10	15/14	80-200	1105-1115
GCLD-100	100-110	18*1.5	2-18	18/13	80-200	1110/1115
GCLD-120	115-128	30*2.0	2-22	25/17	80-200	4105/4110
